Product Details:
|
Type: | CAT 6, CAT5/CAT5e/CAT6/CAT7 | Number Of Conductors: | 8 |
---|---|---|---|
Product Name: | Cat6 Lan Cable | Cable Gauge: | 24AWG/26AWG/28AWG |
Color: | Red/White/Black/Grey/Blue/Green | Conductor: | Bare Copper |
Length: | 10ft | Jacket: | PVC/LSZH |
Shield: | UTP/FTP/SFTP | Warranty: | 1 Year |
Highlight: | Customizable Cat6 Lan Cable,10ft Cat6 Lan Cable,Rj45 Cat6 Lan Cable |
Attribute | Value |
---|---|
Type | CAT 6, CAT5/CAT5e/CAT6/CAT7 |
Number of Conductors | 8 |
Product name | Cat6 Lan Cable |
Cable gauge | 24AWG/26AWG/28AWG |
Color | Red/White/Black/Grey/Blue/Green |
Conductor | Bare Copper |
Length | 10ft |
Jacket | PVC/LSZH |
Shield | UTP/FTP/SFTP |
Warranty | 1 year |
550MHz Bandwidth • 10Gbps Ready • 24AWG Bare Copper
TIA/EIA-568-C.2 Certified RoHS Compliant 100% Copper 550MHz Bandwidth
Supports 10GBASE-T Ethernet at reduced distances (up to 55m) with backwards compatibility to 1000BASE-T.
Delivers up to 90W (802.3bt PoE++) for power-hungry devices like PTZ cameras and WiFi 6 access points.
Precisely twisted 4 pairs with differentiated twist rates to minimize NEXT and FEXT interference.
Parameter | Specification |
---|---|
Conductor Material | 24AWG solid bare copper (±0.002") |
DC Resistance | ≤ 9.38Ω/100m @ 20°C |
Propagation Delay | ≤ 548 ns/100m (max) |
Attenuation @ 250MHz | ≤ 36.6 dB/100m |
PSNEXT | ≥ 42.3 dB @ 250MHz |
Operating Temperature | -20°C to 75°C (-4°F to 167°F) |
Bend Radius | ≥ 8x cable diameter |
