Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord

Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord
Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord

Large Image :  Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord

Product Details:
Place of Origin: Guangdong, China
Brand Name: KUNCAN
Certification: USA,CE,RoHS
Model Number: KC-NT-001
Payment & Shipping Terms:
Minimum Order Quantity: 500 pieces
Price: $0.45 - $0.5/pieces
Packaging Details: PE Bag,carton
Delivery Time: 15days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 3000 Piece/Pieces per Week
Contact Now

Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord

Description
Type: CAT 6, CAT5/CAT5e/CAT6/CAT7/CAT8 Number Of Conductors: 8
Product Name: Patch Cable Cat6 Cable Gauge: 24AWG/26AWG
Color: Red/White/Black/Grey/Blue/Green Conductor: Bare Copper
Length: 2ft-20ft Jacket: PVC
Shield: UTP/FTP/SFTP Warranty: 1 Year
Port: SZ
Highlight:

1m Cat 6 Ethernet Cable

,

Cat 6 Ethernet Cable 30awg

,

Cat6 Patch Cord SFTP Shield

Cat6 Ethernet Cable 24AWG UTP Patch Cord 10Gbps
Product Overview
UTP Cat6 LAN Cable with RJ45 Connectors
550MHz Bandwidth • 10Gbps Ready • 24AWG Bare Copper
Compliant 100% Copper 550MHz Bandwidth
Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord 0 Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord 1 Cat6 Ethernet Cable 24AWG UTP 10Gbps Patch Cord 2
Technical Specifications
  • Category: Cat6 UTP (Unshielded Twisted Pair)
  • Speed: 10Gbps @ 55m / 1Gbps @ 100m
  • Bandwidth: 550MHz
  • Conductor: 24AWG solid bare copper
  • PoE Support: Up to IEEE 802.3bt (PoE++)
  • Jacket: PVC (CM/CMR) or LSZH options
  • Connectors: Gold-plated RJ45 (8P8C)
  • Impedance: 100Ω ±15%
Parameter Specification
Standard Compliance ISO/IEC
Conductor Material 24AWG solid bare copper (±0.002")
DC Resistance ≤ 9.38Ω/100m @ 20°C
Propagation Delay ≤ 548 ns/100m (max)
Attenuation @ 250MHz ≤ 36.6 dB/100m
PSNEXT ≥ 42.3 dB @ 250MHz
Operating Temperature -20°C to 75°C (-4°F to 167°F)
Bend Radius ≥ 8x cable diameter
Available Options
  • Lengths: 0.5m to 305m bulk spools
  • Colors: Blue, Black, White, Red, Green, Yellow
  • Jacket Rating: CM (General), CMR (Riser), CMP (Plenum)
Key Features
10Gbps Performance
Supports 10GBASE-T Ethernet at reduced distances (up to 55m) with backwards compatibility to 1000BASE-T.
Enhanced PoE Support
Delivers up to 90W (802.3bt PoE++) for power-hungry devices like PTZ cameras and WiFi 6 access points.
Precision Engineering
Precisely twisted 4 pairs with differentiated twist rates to minimize NEXT and FEXT interference.
Recommended Applications
  • Network Infrastructure: 10Gbps switches, servers, NAS devices (up to 55m)
  • PoE++ Systems: High-power devices like PTZ cameras, LED lighting
  • Data Centers: Top-of-rack switching, server interconnects
  • AV Systems: HDBaseT extenders, digital signage
  • Gaming/Streaming: Low-latency connections for competitive gaming
Product Attributes
Attribute Value
Type CAT 6, CAT5/CAT5e/CAT6/CAT7/CAT8
Number of Conductors 8
Product name Patch Cable cat6
Cable gauge 24AWG/26AWG
Color Red/White/Black/Grey/Blue/Green
Conductor Bare Copper
Length 2ft-20ft
Jacket PVC
Shield UTP/FTP/SFTP
Warranty 1 year
Frequently Asked Questions
Q1. Are you factory or trade company?
A: We are factory of more than 16 years export experience.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. Samples?
A: 2-5 pieces free samples are available, fright on you. Delivery time usually is 2-3 days. Customized samples will take 5-10days.
Q5. What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 10-15 working days, for more QTY order, let's confirm when you place official order.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q7: How to ship out the cargo?
A: At your request, by sea, by express, all are available.
