This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors

This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors
This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors

Large Image :  This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors

Product Details:
Place of Origin: China
Brand Name: KUNCAN
Model Number: KC-LC-LC
Payment & Shipping Terms:
Minimum Order Quantity: 500Pieces
Price: ＄1.63/Piece 500-900Pieces
Packaging Details: PE Bag +Carton
Delivery Time: 16Days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 1000PCS Per/week
Contact Now

This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors

Description
Highlight:

LC APC Optical Network Patch Cord

,

Angled Physical Contact Patch Cord

,

LC APC Fiber Optic Patch Cord

LC APC Fiber Optic Patch Cable – Green Jacket, Angled Physical Contact Connector, Singlemode Jumper for ODF, FTTH, Telecom Applications

Product Description

  Technical Specifications

Parameter Description
Product Name LC APC Fiber Optic Patch Cord
Connector Type LC/APC to LC/APC
Fiber Mode Singlemode (OS2)
Polish Type Angled Physical Contact (APC)
Cable Structure Simplex / Duplex
Insertion Loss ≤0.3dB (Typical: ≤0.2dB)
Return Loss ≥60dB
Cable Jacket PVC / LSZH
Jacket Color Green
Cable Diameter 2.0mm / 3.0mm
Standard Lengths 0.5m / 1m / 2m / 3m / 5m / 10m / Customized
Operating Temperature -20°C ~ +70°C
Storage Temperature -40°C ~ +85°C


 Product Introduction

This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors, it minimizes back reflection and insertion loss—ideal for FTTH deployments, optical distribution frames, and telecommunication infrastructure.

The green jacket design follows international color coding for APC connectors, allowing for intuitive identification in complex systems.

 Key Specs at a Glance

  • Connector: LC to LC, APC polish

  • Fiber Mode: OS2 Singlemode

  • Length: Customizable (0.5m to 50m)

  • Jacket: Green PVC or LSZH

  • Temp Range: -20°C to +70°C

 Color & Size Options

Fiber Polish Jacket Color Diameter Best Application
LC APC Green 2.0mm FTTH, ODF, Telecom backbone
LC APC Yellow 3.0mm Long-distance SM connections
LC UPC Aqua 2.0mm LAN or short-haul fiber links


 Product Features

  •  Green APC polish for low back reflection (≥60dB)

  •  Precision-molded zirconia ferrule ensures signal integrity

  •  LSZH flame-retardant or standard PVC options

  •  Ideal for high-density fiber applications

  •  100% factory-tested and inspected

 Compatible Applications

  • Fiber to the Home (FTTH)

  • Optical Distribution Frames (ODF)

  • Data center interconnections

  • Telecommunication base stations

  • Passive Optical Network (PON) systems

  • Equipment using LC APC interface

 Safety & Handling Notes

  • Avoid mixing APC and UPC connectors

  • Keep connectors clean and capped when not in use

  • Do not exceed minimum bend radius during installation

  • Avoid excessive pulling tension during routing

  • Store in dry, dust-free environments

 This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors 0This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors 1This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors 2This LC APC Fiber Optic Patch Cord is designed for high-precision optical networks requiring superior signal performance. Featuring an Angled Physical Contact (APC) polish and LC small-form connectors 3

FAQ


Frequently Asked Questions (FAQ)

Q1. Are you factory or trade company?
A: We are factory of more than 16 years export experience.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. Samples ?
A: 2-5 pieces free samples are available, freight on you. Delivery time usually is 2-3 days. Customized samples will take 5-10 days.

Q5. What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 10-15 working days, for more QTY order, let's confirm when you place official order.

Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.

Q7. How to ship out the cargo?
A: At your request, by sea, by express, all are available.
