Product Details:
|
Connection: | Plug In | AC Leakage Current: | 0.25mA Max .At 240V Ac Input |
---|---|---|---|
Input Voltage: | 240V, AC100~240V | Cable Length: | 1m, 2m, Customized |
Over Voltage Protection: | 120% Min | Over Current Protection: | 120% Min |
Short Circuit Protect: | Auto Recovery | Safety Approval: | FCC CE |
Warranty: | 12 Months | ||
Highlight: | 4 in 1 Power Adapter,US EU UK AU Power Adapter,Multi Plug Travel Charger |
Attribute | Value |
---|---|
Connection | Plug In |
AC leakage Current | 0.25mA Max. At 240V ac input |
Input voltage | 240V, AC100~240V |
Cable length | 1m, 2m, customized |
Over voltage protection | 120% min |
Over current protection | 120% min |
Short circuit protect | Auto Recovery |
Safety approval | FCC CE |
Warranty | 12 Months |
Input voltage | AC 100~240V |
Variation Frequency | 50-60Hz |
Input frequence | 50~60Hz |
Output voltage | 12v |
Output current | 2A |
Output power | 24W |
Input plug types | EU/US/UK/AUS/South Korea/South African Plugs |
Out plug types | DC jack, XLR, JST, Cigar Lighter, Alligator Clips, Viation Plug, Din Plug, etc. |
DC jack size | 5.5*2.1mm, 5.5*2.5mm, 3.5*1.35mm, 3.5*1.0mm, 4.0*1.7mm, 2.5*0.7mm, etc. |
Over voltage protection | 120% min |
Over current protection | 120% min |
Short circuit protection | Auto recovery |
Over hot protection | Auto recovery |
Operating Temperature | -40~50°C |
Storage Temperature | -40 to +85 °C |
Humidity | 10%~95%RH |
Efficiency | 80% |
Ripple And Noise | Output voltage 1%, Ripple&Noise≤120mv |
Turn-on Delay Time | 3 second max |
Overshoot at Turn-on | 10% max when turn on or off |
AC leakage Current | 0.25mA max at AC 240V voltage |
Load Regulation | ±5% |
Line Regulation | ±5% |
High-Voltage test | Primary to secondary: 3 kV / 5mA 60S |
Drop Test | 0.75m drop test, 6 times |
Burn-In Test | 100% load, 5hours |
Safe Certificate | CE ROHS FCC CB BS SAA C-tick PSE KC |
