Technical Specifications

Product Introduction

D Sub Mixed Contact Connectors are specialized interface components that combine signal, power, or coaxial contacts in a single compact connector body. These connectors are widely used in industrial control systems, robotic equipment, and communication interfaces where both low-voltage data and high-current power must be transmitted through one port.

 Key Specs

• Mixed Configuration – Combines power and signal contacts in one housing

• High Current Capability – Supports up to 40A on power contacts

• Multiple Mounting Styles – Suitable for panel, PCB, or cable termination

• Secure Connection – Precision shell with locking screws ensures stability

• Custom Layouts – Available in various standard and OEM contact configurations




 Color & Size Options

• Shell Sizes: E / A / B / C / D (based on layout)

• Contact Combinations: 7W2, 13W3, 17W2, 21W4, 9W4, etc.

• Mounting Options: Flange mount / Solder cup / Press-fit / PCB

• Color: Silver / Black (shell) + Natural / Gold-plated contacts

 Product Features

• Compact solution for signal and power in one connector

•  Ideal for automation, transportation, robotics, and telecom industries

•  Standard footprint with flexible layout options

•  Designed for rugged environments with high mating cycles

•  Supports both cable-to-panel and PCB-to-panel connections

Compatible Applications

• Industrial Automation Systems

• CNC Machines and Servo Controllers

• Medical Equipment Interfaces

• Power-Signal Combo Data Terminals

• Custom Embedded Communication Modules

 Safety & Installation Information

• Ensure correct alignment and torque of mounting screws

• Do not exceed rated current/voltage per contact type

• Maintain clean contact surfaces for optimal conductivity

• Store in dry environment, avoid exposure to corrosive chemicals

• Always use proper crimping and termination tools for power pins
