FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center

FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center
FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center

Large Image :  FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center

Product Details:
Place of Origin: China
Brand Name: KUNCAN
Model Number: KC-LC-FC
Payment & Shipping Terms:
Minimum Order Quantity: 500Pieces
Price: ＄1.63/Piece 500-900Pieces
Packaging Details: PE Bag +Carton
Delivery Time: 16Days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 1000PCS Per/week
Contact Now

FC to LC Fiber Optic Patch Cable Singlemode Multimode for Data Center

Description
Highlight:

Single Mode Fiber Optic Patch Cable

,

Multi Mode Fiber Optic Patch Cable

FC to LC Fiber Optic Patch Cable

High-performance jumper cable for data center and telecom applications, available in singlemode or multimode configurations.

Technical Specifications
Parameter Description
Product Name FC to LC Fiber Optic Patch Cord
Connector Type FC/UPC or FC/APC to LC/UPC or LC/APC
Fiber Type Singlemode (OS2) / Multimode (OM1/OM2/OM3/OM4)
Cable Diameter 2.0mm / 3.0mm
Cable Jacket PVC / LSZH / OFNP / OFNR
Insertion Loss ≤0.3dB (Typical: ≤0.2dB)
Return Loss ≥50dB (UPC) / ≥60dB (APC)
Length Options 1m / 2m / 3m / 5m / 10m / Custom
Operating Temperature -20°C ~ +70°C
Jacket Color Yellow (Singlemode), Orange/Aqua (Multimode)
Polish Type UPC / APC
Fiber Count Simplex / Duplex
Certification RoHS compliant
Product Introduction

The FC to LC Optical Fiber Patch Cord is a high-performance jumper cable used in fiber optic communication systems. Designed for reliable, low-loss signal transmission, this patch cord connects FC and LC interfaces for use in data centers, telecom rooms, FTTx, LAN, and test equipment.

Available in singlemode and multimode options, and a variety of lengths, it supports both short-range and long-range signal distribution needs.

Key Specifications
  • Connector: FC (round thread lock) to LC (compact push-pull)
  • Lengths: Available from 0.5m to 50m (custom on request)
  • Fiber Mode: Singlemode (OS2) or Multimode (OM3/OM4)
  • Low Insertion Loss: Typically ≤0.2dB
  • High Return Loss: ≥50dB for UPC, ≥60dB for APC
  • Jacket Type: PVC / LSZH for safety and flexibility
Color & Size Options
  • Singlemode Jacket: Yellow
  • Multimode Jacket: Orange (OM1/OM2), Aqua (OM3), Violet (OM4)
  • Diameter: 2.0mm / 3.0mm
  • Length: 1m ~ 50m or customized
Product Features
  • Precision-polished connectors for optimal performance
  • Low loss and stable transmission over long distances
  • Flame-retardant jacket ensures safety in complex environments
  • Easy identification with color-coded jackets
  • Wide compatibility with telecom and networking equipment
Compatible Devices & Applications
  • ODF (Optical Distribution Frames)
  • Fiber media converters and transceivers
  • Optical switches and test equipment
  • FTTH, FTTB, FTTC installations
  • CATV systems and telecom base stations
Safety & Usage Tips
  • Do not bend the cable below the minimum bend radius
  • Keep dust caps on connectors when not in use
  • Clean the end faces before each insertion
  • Store in dry, room-temperature environments
Frequently Asked Questions (FAQ)
Q1. Are you factory or trade company?

A: We are factory of more than 16 years export experience.

Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery.

Q3. What is your terms of delivery?

A: EXW, FOB, CFR, CIF, DDU.

Q4. Samples?

A: 2-5 pieces free samples are available, freight on you. Delivery time usually is 2-3 days. Customized samples will take 5-10 days.

Q5. What is delivery time if we place an order?

A: It depends order quantities. Usually, we can deliver goods within 10-15 working days, for more QTY order, let's confirm when you place official order.

Q6. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q7. How to ship out the cargo?

A: At your request, by sea, by express, all are available.
