12V Heavy-Duty Male to Male Car Charger Cable
Universal Car Cigar Lighter to OBD2 Diagnostic Cable for Vehicle Scanner with 16ft 12V-24V Safety Certified
Technical Specifications
| Parameter |
Specification |
| Input Voltage |
12V-24V DC |
| Output Voltage |
12V-24V DC |
| Current Rating |
10A Max |
| Cable Length |
1.5M / 3M (Optional) |
| Connector Type |
Dual Male Cigarette Lighter Plugs |
| Wire Material |
Copper Core, PVC Insulation |
| Operating Temperature |
-20°C to 80°C (-4°F to 176°F) |
| Safety Protection |
Overload Protection, Short-Circuit Prevention |
Product Overview
This Dual Male Cigarette Lighter Cable is designed to extend power between two 12V/24V car outlets, enabling seamless connectivity for in-vehicle devices. Ideal for charging dash cams, portable refrigerators, GPS systems, and more, it ensures stable power transmission with reinforced safety features. Crafted from durable materials, it withstands daily wear and extreme temperatures.
Key Features
- Dual Male Plugs: Connect two 12V/24V cigarette lighter sockets for power extension between vehicles or devices
- High-Current Support: Handles up to 15A continuous (180W at 12V / 360W at 24V) with a 15A blade fuse for overload protection
- Safety First: Flame-retardant PVC jacket and reverse polarity protection to prevent accidents
- Rugged Durability: 14 AWG tinned copper wire with oil/abrasion-resistant jacket for harsh environments (-40°C to +105°C)
- Plug-and-Play: Instantly bridge power between cars, trailers, RVs, or portable 12V/24V systems
Physical Specifications
- Color Options: Black, Gray
- Connector Diameter: 2.1cm (0.83")
- Cable Diameter: 4mm (0.16")
Dual-Male Design
Enables power extension between two car lighter sockets.
High-Temperature Resistance
ABS connectors and PVC-coated wires ensure durability in extreme conditions.
Plug-and-Play
No installation required--compatible with most 12V/24V car outlets.
Safety Prioritized
Built-in overload and short-circuit protection for risk-free operation.
Compatible Devices
- Car vacuum cleaners
- Air compressors
- USB chargers
- Dash cameras
- Portable LED lights
- Other 12V/24V automotive accessories
Note: Ensure your device's voltage matches the cable's specifications (12V-24V DC).
Applications
- Trailer/RV Power: Extend 12V power from a tow vehicle to a trailer's lights, fans, or small appliances
- Emergency Charging: Link two vehicles for low-current battery charging (e.g., portable jump starters)
- Portable Power: Connect solar generators, air compressors, or LED light bars between 12V sockets
- DIY Setups: Power 12V tools, coolers, or inverters in off-grid or camping scenarios
Safety Information
Usage Guidelines:
- Do not expose to water or high humidity
- Avoid prolonged use under maximum load (10A)
- Disconnect during vehicle ignition to prevent voltage spikes
- Keep away from flammable materials
Why Choose This Cable?
- Safety Assured: Built-in fuse and reverse polarity protection prevent electrical hazards
- All-Weather Ready: Oil-resistant jacket withstands engine heat, grease, and moisture
- Stable Power Delivery: Thick 14 AWG wire minimizes voltage drop over extended runs
- Universal Compatibility: Works with 12V/24V cars, trucks, boats, and portable power stations
Certifications & Standards
- Safety: IP54 (dust/splash resistance)
- Environmental: RoHS, REACH
Warranty: 12-month warranty (excludes fuse replacement or physical damage).
Note: For low-power devices only - do not exceed 15A continuous load. Confirm socket compatibility before use.
Critical Safety Warnings
- NOT FOR JUMP-STARTING - cigarette lighter circuits are not rated for starter motor currents
- Avoid daisy-chaining multiple cables - risk of overheating and fire
- Disconnect during vehicle ignition to prevent voltage surges
Compatible with 12V/24V DC systems. Not for AC power, EV hybrids, motors, or inductive loads.
For charging secondary batteries, use a dedicated DC-DC charger. Never exceed 15A continuous draw.
Frequently Asked Questions
Q1. Are you factory or trade company?
A: We are factory of more than 16 years export experience.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. Samples?
A: 2-5 pieces free samples are available, freight on you. Delivery time usually is 2-3 days. Customized samples will take 5-10 days.
Q5. What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 10-15 working days, for more QTY order, let's confirm when you place official order.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q7. How to ship out the cargo?
A: At your request, by sea, by express, all are available.
